HEPA Filters, Supply Outlets, Self-Purifiers & Clean Benches

Name: HEPA Filters & FFU
Brand: BESTCLEAN

Terminal filtration for new-build and retrofit cleanrooms — from a single HEPA outlet to a full FFU ceiling. Confirm the selected filter grade, test method, rated airflow and installed-system acceptance requirements for your project.

Mini-pleat HEPA filters without separator

High efficiency HEPA air filters with frame

Vertical laminar flow clean bench double person

Product Lines

Mini-pleat HEPA filters (no separator): 305–1220mm modules, 350–2,400 m³/h, ultra-fine fiber paper media
High-efficiency HEPA filters: glass-fiber media, low resistance, high dust capacity; standard & high-temp types
Primary & medium filters: bag type, panel type, activated carbon
HEPA supply outlets: replaceable-filter or disposable one-piece design; top or side duct connection; filter grade and test records to be confirmed
Liquid-tank sealed outlets: liquid-seal configuration; installed integrity testing and acceptance limits to be agreed
Air self-purifier (ceiling type): catalogue airflow of 800–1,500 m³/h per unit; room classification requires system design and on-site testing
Clean benches: horizontal & vertical laminar flow, single/double person, SUS worktop, adjustable fan speed

Send Size List for Quote Datasheet PDF ↓

Air Self-Purifier (Ceiling / Embedded)

Model	External W×D×H (mm)	HEPA Filter (mm)	Airflow	Mounting
BJ-PAU-600	710×710×550	600×600×150	800 m³/h	Ceiling / Embedded
BJ-PAU-800	930×710×550	820×600×150	1,000 m³/h
BJ-PAU-1000	1025×710×550	915×600×150	1,500 m³/h

Clean Bench Models

Type	Model Size W×D×H (mm)	Persons	Airflow Direction
Horizontal laminar	900×700×1450	Single, one side	Horizontal
Horizontal laminar	1500×700×1450	Double, one side	Horizontal
Vertical laminar (medical)	1000×780×1620	Single	Vertical
Vertical laminar (medical)	1500×780×1620	Double	Vertical

Retrofitting or building new?

Send your ceiling grid sizes or filter dimensions — mixed-size orders welcome, 7–15 day production.

Request a Quote

Before requesting a quotation

HEPA and FFU Procurement: Evidence, Interfaces and Acceptance — prepare comparable requirements and acceptance questions.

Original factory documentation

Review BERKING catalogue sources, page references and the BESTCLEAN company relationship. Confirm current specifications, project references and document scope for your order.

Check the evidence behind your quotation

For equipment procurement, match each document to the quoted model and configuration. Record the test conditions, document holder and any questions still open.

Use this 20-item worksheet for cleanroom projects and equipment. It is a buyer review aid, not a certificate or confirmation that a particular document is available.

Download the evidence checklist (CSV)

Review original factory documentation · Request documents for your quotation
